HP OMEN 25L Gaming Desktop PC GT11 Intel Core i7 10700F (8 Cores) 16GB Ram 256GB SSD 1TB HDD 8GB RTX 2060 Graphics

HP OMEN 25L GT11 Desktop Specifications

HP OMEN 25L Gaming

1. General Information

• Model Series: HP OMEN 25L Gaming

• Type: Gaming Desktop PC

• Release Year: 2020

• Operating System:  Windows 11

• Chassis Color: Black

• Chassis Material: Metal case with tempered glass side panel (on some models) or solid metal panel

• Dimensions (W x D x H): 16.51 x 36.9 x 43.31 cm (6.5 x 15.53 x 17.05 inches)

• Weight: 11.36 – 11.46 kg (25.04 – 25.26 lbs)

2. Processor (CPU)

• Brand: Intel®

• Family: 10th Generation Intel® Core™ i7 (Comet Lake-S)

• Model: Intel® Core™ i7-10700F

• Cores/Threads: 8 Cores / 16 Threads

• Base Clock: 2.90 GHz

• Max Turbo: Up to 4.70 GHz with Intel® Turbo Boost Technology

• Cache: 16 MB Intel Smart Cache

• TDP: 65 W

• Socket Type: LGA 1200

• Integrated Graphics: No (F series processor requires dedicated GPU)

3. Motherboard

• Motherboard Name: Dorado

• Form Factor: Micro ATX: 24.0 x 24.0 cm (9.45 x 9.45 in)

• Chipset: Intel H470

• Processor Socket: LGA 1200

• Memory Sockets: 4 x DDR4 (288-pin) UDIMM slots

• Expansion Slots:

  • One PCIe x16 Gen 3 socket (for discrete graphic card)

  • One M.2 socket 1, key A

  • One M.2 socket 3, key M (for SSD)

4. Memory (RAM)

• Capacity: 16 GB DDR4

• Speed: 2933 MHz (PC4-23400)

• Configuration: Dual-channel (2 x 8 GB) HyperX XMP memory

• Memory Slots: 4 slots total (2 occupied)

• Maximum Supported: Up to 64 GB (with 16 GB DIMMs on 64-bit systems)

5. Storage – Dual Drive Configuration

• Primary Drive (SSD): 256 GB PCIe NVMe M.2 SSD (WD Black)

  • Interface: PCIe Gen 3

  • Form Factor: M.2 2280

• Secondary Drive (HDD): 1 TB 7200 RPM SATA HDD

  • Interface: SATA 6.0 Gb/sec

  • Rotational Speed: 7200 RPM

• Storage Expansion: Additional drive bays available for future upgrades

6. Graphics (GPU)

• Model: NVIDIA® GeForce RTX™ 2060 Super

• Memory: 8 GB GDDR6 dedicated

• Form Factor: Full height PCB with ATX dual slot bracket

• Rear I/O Connectors:

  • 1x HDMI 2.0b

  • 3x DisplayPort 1.4a

  • 1x DVI-D (on some models)

• Maximum Resolution Support:

  • HDMI: Up to 4096×2160 @ 60Hz

  • DisplayPort: Up to 7680×4320 @ 60Hz

• PCIe Interface: PCIe Gen 3 x16

7. Audio

• Audio Codec: Realtek ALC3866-CG

• Audio Features:

  • OMEN Audio Control Support DTS:X Ultra

  • DTS Headphone:X

  • High Definition 5.1 channel audio support

  • HP Audio Switch software

8. Networking & Connectivity

• Wireless: Intel® Wi-Fi 6 AX201 (2×2)

  • Transmission Standards: 802.11ax

  • Dual Band: 2.4 GHz and 5.0 GHz

  • Max Speed: 2.4 Gbps

  • MU-MIMO support

• Bluetooth: Bluetooth® 5.0/5.1 combo

• LAN (Ethernet): Realtek RTL8118 ASH-CG Gigabit Ethernet

  • Data Transfer Speeds: Up to 10/100/1000 Mb/s

9. Front I/O Ports

• USB 3.2 Gen 1 Type-A (5 Gbps, Battery Charging 1.2): 2x

• Headphone/Microphone Combo Jack: 1x

• Microphone Jack: 1x

• Power Button

10. Back I/O Ports

• RJ-45 Ethernet port: 1x

• Audio ports (line-in/line-out/microphone): 3x

• USB 2.0 Type-A ports: 2x

• USB 3.2 Gen 1 Type-A (5 Gbps): 2x

• USB 3.2 Gen 2 Type-A (10 Gbps): 2x

• USB 3.2 Gen 2 Type-C (10 Gbps): 1x

11. Power Supply

• Type: Internal PSU 500 W

• Efficiency Rating: Bronze certified

• Full Range: 115 V / 230 V auto-switching

12. Cooling System

• Technology: OMEN Tempest Cooling Technology

  • Optimized airflow design

  • Developed in collaboration with Cooler Master

  • Customizable fan curves via OMEN Command Center

13. Software & Gaming Features

• Gaming Hub: OMEN Command Center (predecessor to OMEN Gaming Hub) for performance tuning, lighting control, and system vitals

14. Additional Features

• RGB Lighting: Customizable RGB lighting effects configurable through OMEN Command Center

• Tool-less Access: Easy access to interior for upgrades and maintenance

• Disc Drive: None included

• Keyboard  Gaming Keyboard as a bundle addition
